Hi-Low Hydraulic Power Unit, 7,5 Hp, 48 L/min, Max Pressure 185 bar

Hi Low Hydraulip Power Unit 7.5 Hp electric motor, 48 L / min hydraulic pump. 50 bar @ 48.82 L / min and 185 bar @ 15.3 L / min.

Read more
Fuera de stock
Availability date: 2018-02-26
Add to wishlist
Related products

Hi Low Hydraulic Power Unit, 7,5 Hp, 48 L/min, Max Working Pressure 185 bar

This hydraulic group starts operating with a flow of 48 L / min up to a maximum pressure of 55 bar, once the 55 bar barrier has been exceeded, the system reduces the flow to 15.3 L / min up to a maximum pressure of 185 bar. Taking into account that when the system reaches 55 bar, the cylinder is already completely full, it only needs to advance a few centimeters, which is achieved quickly with a flow of 15.3 L / min.

Technical specifications:

  • Double Hydraulic Pump 24+10,6 cc/rev.
  • Low pressure flow: 50 L / min @ 55 bar.
  • High pressure flow: 15 L / min @ 185 bar.
  • Three-phase electric motor 5.5 Kw 1450 Rpm 50 Hz.
  • High and low pressure block.
  • Suction filter (2 units).
  • High pressure gauge: 0-250 bar.
  • Pressure Gauge Excluder.
  • Return filter.
  • Filter dirt indicator.
  • Oil level with thermometer.
  • Tank 100L.
  • Motor-pump coupling hood.
  • Flexible coupling.
  • 4-way 2-position solenoid valve 110 VAC.
  • In-line non-return solenoid valve 110 VAC.
  • Fittings + Flexible
  • Pump flanges.
  • Assembly + Test + Painting.
